Sapphire NC24

Coronary Dilatation Catheter

Optimal combination of robustness,
controlled compliance,
and re-crossability

True Controlled Balloon Compliance

Lowest % Circumferential Growth*
(Nom to RBP)

*Data on in-house bench test data on Ø 3.0 mm balloons

Lowest % Longitudinal Growth*
(Nom to RBP)

Minimal circumferential and longitudinal growth (Nom to RBP) for maximum accuracy and safety during lesion preparation and stent optimization.

High Pressure Tolerance

High pressure tolerance of 24 atm RBP up to 3.5 mm diameter without compromising crossability

Broad range in Balloon Sizes and Lengths

Diameter range from 1.5 to 5.0 mm with lengths up to 26 mm for broadened range of treatment

G-70-1145 Rev01

Technical Specifications

Catheter Type	Rapid Exchange
Proximal Shaft	2.1F
Distal Shaft	2.36F – 2.7F (Ø1.5 mm – 5.0 mm)
Catheter Working Length	140 cm
Tip Length	1.5 mm (Ø1.5 mm -1.75 mm); 2.0 mm (Ø2.0 mm – 3.0 mm); 2.5 mm (Ø3.25 mm – 5.0 mm)
Marker Bands	1 (Ø1.5 mm); 2 (Ø1.75 mm – 5.0 mm)
Crossing Profile (Ø3.0 mm)	0.0345”
Coating	Hydrophilic (tip to guidewire exit port); Hydrophobic (guidewire lumen)
Nominal Pressure (NOM)	14 atm
Rated Burst Pressure (RBP)	24 atm (Ø1.5 mm – 3.5 mm); 22 atm (Ø3.75 mm – 4.0 mm); 20 atm (Ø4.5 mm – 5.0 mm)
Balloon Material	Nylon and Pebax (dual layer)
Balloon Folds	3 (Ø1.5 mm – 4.0 mm); 5 (Ø4.5 mm – 5.0 mm)
Balloon Diameters (mm)	1.5, 1.75, 2.0, 2.25, 2.5, 2.75, 2.875, 3.0, 3.25, 3.5, 3.75, 4.0, 4.5, 5.0
Balloon Lengths (mm)	8, 10, 12, 15, 18, 22, 26
Guiding Catheter Compatibility	5F (Ø1.5 mm – 4.00 mm); 6F (Ø4.5 mm – 5.0 mm)

Schematic

Compliance Chart

Pressure (atm)	Balloon Diameter (Ø mm)
	1.5	1.75	2.0	2.25	2.5	2.75	2.875	3.0	3.25	3.5	3.75	4.0	4.5	5.0
8	1.44	1.70	1.95	2.20	2.44	2.68	2.81	2.91	3.17	3.41	3.66	3.89	4.37	4.85
10	1.46	1.72	1.97	2.21	2.46	2.70	2.83	2.94	3.19	3.44	3.69	3.93	4.41	4.90
12	1.48	1.73	1.98	2.23	2.48	2.73	2.85	2.97	3.22	3.47	3.72	3.96	4.46	4.95
14 (NOM)*	1.50	1.75	2.00	2.25	2.50	2.75	2.875	3.00	3.25	3.50	3.75	4.00	4.50	5.00
16	1.52	1.77	2.02	2.27	2.52	2.77	2.90	3.03	3.28	3.53	3.78	4.04	4.54	5.05
18	1.54	1.78	2.03	2.29	2.54	2.80	2.92	3.06	3.31	3.56	3.81	4.07	4.59	5.10
20 (RBP)	1.56	1.80	2.05	2.30	2.56	2.82	2.94	3.09	3.33	3.59	3.84	4.11	4.63	5.15
22 (RBP)**	1.58	1.82	2.07	2.32	2.58	2.84	2.96	3.12	3.36	3.62	3.87	4.15	4.67	5.21
24 (RBP)**	1.60	1.84	2.09	2.34	2.60	2.86	2.99	3.15	3.39	3.65	3.90	4.19	4.71	5.26
26	1.62	1.85	2.10	2.36	2.62	2.89	3.01	3.18	3.42	3.68	3.93	4.22	—-	—-
28	1.64	1.87	2.12	2.38	2.64	2.91	3.03	3.20	3.45	3.71	—-	—-	—-	—-
30	1.66	1.89	2.14	2.39	2.66	2.93	3.05	3.23	3.47	3.74	—-	—-	—-	—-

* Nominal Pressure. The nominal in vitro device specifications do not take into account any lesion resistance.
**Rated Burst Pressure. Do not exceed RBP

G-70-1146 Rev02

Available Configurations

Balloon Diameter ( Ø mm)	Balloon Working Length (mm)
	8	10	12	15	18	22	26
1.5	●	●	●	●	●	●	●
1.75	●	●	●	●	●	●	●
2.0	●	●	●	●	●	●	●
2.25	●	●	●	●	●	●	●
2.5	●	●	●	●	●	●	●
2.75	●	●	●	●	●	●	●
2.875	●	●	●	●	●	●	●
3.0	●	●	●	●	●	●	●
3.25	●	●	●	●	●	●	●
3.5	●	●	●	●	●	●	●
3.75	●	●	●	●	●	●	●
4.0	●	●	●	●	●	●	●
4.5	●	●	●	●	●	●	●
5.0	●	●	●	●	●	●	●

G-70-1147 Rev01

G-70-1063 Rev05 (Non-EU) Sapphire NC24 Brochure

G-70-1069 Rev06 (EU) Sapphire NC24 Brochure

G-70-1178 Rev02

Sapphire® NC 24 is approved for sale in the USA. Federal Law (US) restricts this device to sale by or on order of a physician.
