JADE

PTA Balloon Catheter

For Percutaneous
Transluminal Angioplasty

Hybrid OTW/RX Design

JADE has a 60 cm lumen tracking section, making this a hybrid Rapid exchange/Over-the-Wire construction.
JADE’s extended Rx section allows better pushability than a traditional Rapid Exchange catheter.

Balloon Compliance

JADE is a non-compliant balloon for controlled opening of resistant lesions.

Compliance of 2.0 mm balloons

Rated Burst Pressure

JADE has the highest rated burst pressure amongst competitor products of the same class.

Rated Burst Pressure* Comparison

measured in ATM

Source: Competitor websites

Lubricious Coating

Hydro-X Hydrophilic coating on distal shaft for added crossability

Hydro-X hydrophilic coating adds lubricity to reduce friction to enhance crossability.

IMPROVES CROSSABILITY

Invio hydrophobic coating is water-repellent and minimizes guidewire friction.

IMPROVES TRACKABILITY

G-70-0693 Rev02

Catheter Type	Rapid Exchange
Minimum Sheath Size	4F (Ø 1.5 mm – 3.5 mm); 5F (Ø 4.0 mm – 5.0 mm); 6F (Ø 5.5 mm – 6.0 mm)
Guidewire Compatibility	0.014”
Catheter Working Length	150 cm
Proximal Shaft Diameter	2.8F (Ø 1.5 mm – 2.5 mm); 3.3F (Ø 3.0 mm – 3.5 mm); 4.0F (Ø 4.0 mm – 6.0 mm)
Distal Shaft Diameter	3.3F (Ø 1.5 mm – 2.5 mm); 3.7F (Ø 3.0 mm – 3.5 mm); 4.2F (Ø 4.0 mm – 6.0 mm)
Balloon Material	Nylon/Pebax
Compliance	Controlled compliance
Leading Tip Length	3.0 mm (Ø 1.5 mm – 3.0 mm); 4.0 mm (Ø 3.5 mm – 4.5 mm); 5.0 mm (Ø 5.0 mm – 6.0 mm)
Marker Bands	2 marker bands (Ø 15 mm – 120 mm); 4 marker bands (Ø 180 mm & 240 mm)
Coating	Hydrophilic (tip, balloon, & distal shaft), Hydrophobic (guidewire lumen)
Crossing Profile	0.039” (∅3.0 mm)
Nominal Pressure	12 atm
Rated Burst Pressure	22 atm (Ø 1.5 mm – 4.0 mm); 20 atm (Ø 4.5 mm – 5.0 mm); 18 atm (Ø 5.5 mm – 6.0 mm)

Catheter Type

Rapid Exchange

Minimum Sheath Size

4F (Ø 1.5 mm – 3.5 mm);
5F (Ø 4.0 mm – 5.0 mm); 6F (Ø 5.5 mm – 6.0 mm)

Guidewire Compatibility

0.014”

Catheter Working Length

150 cm

Proximal Shaft Diameter

2.8F (Ø 1.5 mm – 2.5 mm); 3.3F (Ø 3.0 mm – 3.5 mm); 4.0F (Ø 4.0 mm – 6.0 mm)

Distal Shaft Diameter

3.3F (Ø 1.5 mm – 2.5 mm); 3.7F (Ø 3.0 mm – 3.5 mm); 4.2F (Ø 4.0 mm – 6.0 mm)

Balloon Material

Nylon/Pebax

Compliance

Controlled compliance

Leading Tip Length

3.0 mm (Ø 1.5 mm – 3.0 mm); 4.0 mm (Ø 3.5 mm – 4.5 mm); 5.0 mm (Ø 5.0 mm – 6.0 mm)

Marker Bands

2 marker bands (Ø 15 mm – 120 mm); 4 marker bands (Ø 180 mm & 240 mm)

Coating

Hydrophilic (tip, balloon, & distal shaft),
Hydrophobic (guidewire lumen)

Crossing Profile

0.039” (∅3.0 mm)

Nominal Pressure

12 atm

Rated Burst Pressure

22 atm (Ø 1.5 mm – 4.0 mm); 20 atm (Ø 4.5 mm – 5.0 mm); 18 atm (Ø 5.5 mm – 6.0 mm)

Pressure	(atm)	Balloon Diameter (mm)
	1.5	2.0	2.5	3.0	3.5	4.0	4.5	5.0	5.5	6.0
2	1.41	1.88	2.37	2.82	3.27	3.70	4.22	4.67	5.09	5.60
4	1.43	1.90	2.40	2.86	3.32	3.76	4.27	4.74	5.17	5.68
6	1.45	1.93	2.42	2.89	3.36	3.82	4.33	4.80	5.26	5.76
8	1.47	1.95	2.45	2.93	3.41	3.88	4.39	4.87	5.34	5.84
10	1.48	1.98	2.47	2.96	3.45	3.94	4.44	4.93	5.42	5.92
12 NOM*	1.50	2.00	2.50	3.00	3.50	4.00	4.50	5.00	5.50	6.00
14	1.52	2.02	2.53	3.04	3.55	4.06	4.56	5.07	5.58	6.08
16	1.53	2.05	2.55	3.07	3.59	4.12	4.61	5.13	5.66	6.16
18 RBP**	1.55	2.07	2.58	3.11	3.64	4.18	4.67	5.20	5.74	6.24
20 RBP**	1.57	2.10	2.60	3.14	3.68	4.24	4.73	5.26	5.83	6.32
22 RBP**	1.59	2.12	2.63	3.18	3.73	4.30	4.78	5.33	5.91	6.40
24	1.60	2.14	2.65	3.22	3.78	4.36	4.84	5.40	–	–
26	1.62	2.17	2.68	3.25	3.82	4.42	–	–	–	–

Pressure

(atm)

Balloon Diameter (mm)

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

1.41

1.88

2.37

2.82

3.27

3.70

4.22

4.67

5.09

5.60

1.43

1.90

2.40

2.86

3.32

3.76

4.27

4.74

5.17

5.68

1.45

1.93

2.42

2.89

3.36

3.82

4.33

4.80

5.26

5.76

1.47

1.95

2.45

2.93

3.41

3.88

4.39

4.87

5.34

5.84

1.48

1.98

2.47

2.96

3.45

3.94

4.44

4.93

5.42

5.92

12 NOM*

1.50

2.00

2.50

3.00

3.50

4.00

4.50

5.00

5.50

6.00

1.52

2.02

2.53

3.04

3.55

4.06

4.56

5.07

5.58

6.08

1.53

2.05

2.55

3.07

3.59

4.12

4.61

5.13

5.66

6.16

18 RBP**

1.55

2.07

2.58

3.11

3.64

4.18

4.67

5.20

5.74

6.24

20 RBP**

1.57

2.10

2.60

3.14

3.68

4.24

4.73

5.26

5.83

6.32

22 RBP**

1.59

2.12

2.63

3.18

3.73

4.30

4.78

5.33

5.91

6.40

1.60

2.14

2.65

3.22

3.78

4.36

4.84

5.40

–

1.62

2.17

2.68

3.25

3.82

4.42

–

Balloon Diameter Ø (mm)	Balloon Working Length (mm)
	15	20	40	80	120	180	240
1.5	●	●	●	●	●	●	●
2.0	●	●	●	●	●	●	●
2.5	–	●	●	●	●	●	●
3.0	●	●	●	●	●	●	●
3.5	–	●	●	●	●	●	●
4.0	●	●	●	●	●	●	●
4.5	–	●	●	●	●	–	–
5.0	●	●	●	●	●	●	●
5.5	–	●	●	●	●	–	–
6.0	●	●	●	●	●	●	●

Balloon Diameter Ø (mm)

Balloon Working Length (mm)

120

180

240

1.5

●

2.0

●

2.5

–

●

3.0

●

3.5

–

●

4.0

●

4.5

–

●

–

5.0

●

5.5

–

●

–

6.0

●
