Home » Peripheral Portfolio » Balloons » Non-compliant » JADE OTW Series

JADE OTW Series

PTA Balloon Catheter

Superb strength, controlled
compliance and deliverability

JADE PTA for Peripheral Anatomy

Non-Compliant Balloon *

JADE has even pressure distribution to minimize dog-bone effect.

G-70-1947 Rev01

Technical Specifications

	014	018	035
Catheter Type	Over the wire	Over the wire	Over the wire
Minimum Sheath Size (Ø in mm)	4 F (Ø 1.5 – 3.5); 5 F (Ø 4.0 – 5.0); 6 F (Ø 6.0)	4 F (Ø 2.0 – 3.0); 5 F (Ø 3.5 – 5.0); 6 F (Ø 5.5 – 7.0)	5 F (Ø 3.0 – 4.0); 6 F (Ø 5.0 – 6.0); 7F (Ø 7.0)
Guidewire Compatibility	0.014″	0.018″	0.035″
Catheter Working Length (cm)	90, 150, 200	90, 150, 200	75, 135, 200
Balloon Material (Ø in mm)	Nylon (Ø 1.5 – 3.5); Nylon/Pebax (Ø 4.0 – 6.0)	Nylon (Ø 1.5 – 3.5); Nylon/Pebax (Ø 4.0 – 7.0)	Nylon (Ø 1.5 – 3.5); Nylon/Pebax (Ø 4.0 – 7.0)
Balloon Compliance	Non-Compliant	Non-Compliant	Non-Compliant
Marker Bands	2 (20 – 150 mm); 4 (180 & 240 mm)	2 (20 – 150 mm); 4 (180 & 240 mm)	2 (20 – 150 mm); 4 (180 & 240 mm)
Coating	Hydrophilic (tip & distal shaft); Hydrophobic (guidewire lumen)	Hydrophilic (tip & distal shaft); Hydrophobic (guidewire lumen)	Hydrophilic (tip & distal shaft); Hydrophobic (guidewire lumen)
Nominal Pressure (Ø in mm)	12 atm (Ø 1.5 – 6.0)	12 atm (Ø 1.5 – 6.0); 10 atm (Ø 7.0)	12 atm (Ø 3.0 – 6.0); 10 atm (Ø 7.0)
Rated Burst Pressure (Ø in mm)	20 atm (Ø 1.5 – 4.0); 18 atm (Ø 5.0 – 6.0)	20 atm (Ø 1.5 – 4.0); 18 atm (Ø 5.0 – 6.0); 16 atm (Ø 7.0)	20 atm (Ø 3.0 – 4.0); 18 atm (Ø 5.0 – 6.0); 16 atm (Ø 7.0)

Compliance chart

Pressure (atm)	Balloon Diameter (Ø mm)
	1.5¹	2.0¹	2.5¹	3.0	3.5¹	4.0	4.5²	5.0	5.5²	6.0	7.0³
2	1.41	1.88	2.37	2.82	3.27	3.70	4.22	4.67	5.09	5.60	6.64
4	1.43	1.90	2.40	2.86	3.32	3.76	4.27	4.74	5.17	5.68	6.73
6	1.45	1.93	2.42	2.89	3.36	3.82	4.33	4.80	5.26	5.76	6.82
8	1.47	1.95	2.45	2.93	3.41	3.88	4.39	4.87	5.34	5.84	6.91
10 NOM*	1.48	1.98	2.47	2.96	3.45	3.94	4.44	4.93	5.42	5.92	7.00
12 NOM*	1.50	2.00	2.50	3.00	3.50	4.00	4.50	5.00	5.50	6.00	7.09
14	1.52	2.02	2.53	3.04	3.55	4.06	4.56	5.07	5.58	6.08	7.18
16 RBP**	1.53	2.05	2.55	3.07	3.59	4.12	4.61	5.13	5.66	6.16	7.27
18 RBP**	1.55	2.07	2.58	3.11	3.64	4.18	4.67	5.20	5.74	6.24	7.36
20 RBP**	1.57	2.10	2.60	3.14	3.68	4.24	4.73	5.26	5.83	6.32	7.45
22	1.59	2.12	2.63	3.18	3.73	4.30	4.78	5.33	5.91	6.40	–
24	1.60	2.14	2.65	3.22	3.78	4.36	4.84	5.40	–	–	–
26	1.62	2.17	2.68	3.25	3.82	4.42	–	–	–	–	–

¹ 1.5, 2.0, 2.5 and 3.5 mm configurations are available only for 014 and 018 platforms.
² available only for 018 system.
³ 7.0 mm configurations are available only for 018 and 035 platforms.
*Nominal Pressure. The nominal in-vitro device specifications do not take into account any lesion resistance.
**Rated Burst Pressure. Do not exceed RBP.

G-70-1946 Rev01³²

Available Configurations for 014 system

Balloon Diameter (Ø mm)	Balloon Length* (mm)
	20	40	60	80	100	120	150	180	240	Sheath
1.5	●	●	–	●	–	●	–	●	●	4F
2.0	●	●	●	●	●	●	●	●	●	4F
2.5	●	●	●	●	●	●	●	●	●	4F
3.0	●	●	●	●	●	●	●	●	●	4F
3.5	●	●	●	●	●	●	●	●	●	4F
4.0	●	●	●	●	●	●	●	●	●	5F
5.0	●	●	●	●	●	●	●	●	●	5F
6.0	●	●	●	●	●	●	●	●	●	6F

*Same size for 90 cm, 150 cm, 200 cm catheter length

Available Configurations for 018 system

Balloon Diameter (Ø mm)	Balloon Length* (mm)
	20	40	60	80	100	120	150	180	240	Sheath
1.5	●	●	–	●	–	●	–	●	●	4F
2.0	●	●	●	●	●	●	●	●	●	4F
2.5	●	●	●	●	●	●	●	●	●	4F
3.0	●	●	●	●	●	●	●	●	●	4F
3.5	●	●	●	●	●	●	●	●	●	5F
4.0	●	●	●	●	●	●	●	●	●	5F
4.5	●	●	–	●	–	●	–	–	–	5F
5.0	●	●	●	●	●	●	●	●	●	5F
5.5	●	●	–	●	–	●	–	–	–	6F
6.0	●	●	●	●	●	●	●	●	●	6F
7.0	●	●	●	●	●	–	●	–	–	6F

*Same size for 90 cm, 150 cm, 200 cm catheter length

Available Configurations for 035 system

Balloon Diameter (Ø mm)	Balloon Length* (mm)
	20	40	60	80	100	120	150	180	240	Sheath
5.0	●	●	●	●	●	–	●	●	●	6F
6.0	●	●	●	●	●	–	●	●	●	6F
7.0	●	●	●	●	●	–	●	●	–	7F
Balloon Diameter (Ø mm)	Balloon Length** (mm)
	20	40	60	80	100	120	150	180	240	Sheath
3.0	●	●	●	●	–	–	●	●	–	5F
4.0	●	●	●	●	●	–	●	●	●	5F
5.0	●	●	●	●	●	–	●	●	●	6F
6.0	●	●	●	●	●	–	●	●	●	6F
7.0	●	●	●	●	●	–	●	●	–	7F

*Sizes for 75 cm catheter length
**Same size for 135 cm, 200 cm catheter length

G-70-1948 Rev01

G-70-1391 Rev04 JADE OTW Brochure (APAC)

G-70-2333 Rev01 JADE OTW Brochure (EMEA)

G-70-1949 Rev04

Jade® is approved for sale in the USA. Caution: Federal Law (US) restricts this device to sale by or on order of a physician.
